The structural form of the crane

The crane is a multi-action lifting machinery that lifts straight and carries heavy objects horizontally within a certain range.Some of the operation characteristics of the crane are intermittent movements, that is, the corresponding organization of reclaiming, moving, unloading and other actions in an operation cycle is alternately operated, and the development and use of cranes in the market are becoming more and more extensive.Lifting machinery can be divided into light and small lifting equipment, lifts, cranes and overhead monorail systems according to different structures.Light and small lifting equipment mainly includes lifting pulleys, spreaders, jacks, manual hoists, electric hoists and ordinary winchs, most of which are small in size, light in weight and easy to use.They can be used on their own, and some can also be used as lifting organizations for cranes.

The structure of the crane is generally composed of three parts: one is the frame; the second is organization (including lifting organization, operation organization, rotation organization, luffing organization, etc.); The third is the control system.

1.racks

The frame is mainly composed of bridge, trolley frame, operation room and escalator and other components, which constitute the main body of the crane.

2.organization

For overhead cranes, there are only two kinds of organization, one is the lifting organization, and the other is the operation organization.

The trolley of the overhead crane has two kinds of organization: lifting and running.The trolley is equipped with a large and a small winch for lifting heavy objects.The big winch, also known as the big hook, is set in the middle of the trolley.The lifting component is available in 8t, 10t, 15t, 20t, 25t, 30t, 40t, 50t, 60t and other standards.The small winch, also known as the small hook, is set on the right side of the trolley, and the lifting component also has a variety of standards such as 1t, 1.5t, 2t, 2.5t, 3t, 4t, 5t, 8t, 10t, 15t, etc.On the left side of the big winch, a small running organization is set up to provide power for the trolley to run left and right on the bridge track.The bridge frame of the overhead crane is also called a cart, and the shape is II Shape.Its four corners are equipped with large wheels and running organization, which can make the crane run along the longitudinal front and back of the workshop.With the cooperation of the cart and the trolley, the heavy object can be lifted to any position within the plane of the workshop.

3.Control system

The lifting and lowering of heavy objects, the left and right running of the trolley on the bridge, and the front and rear operation of the trolley in the workshop can be completed.
