Single girder overhead crane end beam
| Quantity: | |
|---|---|
The end beam of a single-girder crane is the core load-bearing and traveling component of the single-girder crane. It connects the main beam and the operating mechanism, directly determining the overall operating stability and safety performance of the equipment. It is widely applicable to various industrial crane scenarios.
| Parameter Category | Conventional Parameters | Description |
| Basic Parameters | Material | Q235B/Q355B high-strength steel |
| Cross-Section Type | Box-section (mainstream) | |
| End Beam Length | 1200mm-3500mm (suitable for span 6-30m) | |
| Performance Parameters | Rated Load Capacity | 5t, 10t, 16t, 20t |
| Trolley Travel Speed | 20m/min-30m/min (standard, adjustable) | |
| Wheel Set | Wheel diameter φ270mm, material 45# steel (quenched and tempered) | |
| Environmental Parameters | Applicable Working Conditions | Normal temperature, dusty, slightly corrosive environment (custom anti-corrosion coating required) |
| Protection Class | IP54 for travel mechanism (motor part) | |
| Surface Treatment | Shot blasting derusting (Sa2.5 grade) + primer + topcoat (dry film thickness ≥80μm) | |
| Inspection Requirement | Nondestructive testing (UT/MT) for key welds, load test before delivery |
The above are some general parameters of the end beam of single beam crane.
